A new method to improve the survival rate of Android application processes (Part 2)

A new method to improve the survival rate of Android application processes (Part 2)

[[179903]]

Continued from previous article

  • Create Account Service
  1. public class XXAuthService extends Service {
  2. private XXAuthenticator mAuthenticator;
  3.
  4. @Override
  5. public void onCreate() {
  6. mAuthenticator = new XXAuthenticator(this);
  7. }
  8.
  9. private XXAuthenticator getAuthenticator() {
  10. if (mAuthenticator == null )
  11. mAuthenticator = new XXAuthenticator(this);
  12. return mAuthenticator;
  13. }
  14.
  15. @Override
  16. public IBinder onBind(Intent intent) {
  17. return getAuthenticator().getIBinder();
  18. }
  19.
  20. class XXAuthenticator extends AbstractAccountAuthenticator {
  21. private final Context context;
  22. private AccountManager accountManager;
  23. public XXAuthenticator(Context context) {
  24. super(context);
  25. this.context = context;
  26. accountManager = AccountManager.get(context);
  27. }
  28.
  29. @Override
  30. public Bundle addAccount(AccountAuthenticatorResponse response, String accountType, String authTokenType, String[] requiredFeatures, Bundle options)
  31. throws NetworkErrorException {
  32. // Add account sample code
  33. final Bundle bundle = new Bundle();
  34. final Intent intent = new Intent(context, AuthActivity.class);
  35. intent.putExtra(AccountManager.KEY_ACCOUNT_AUTHENTICATOR_RESPONSE, response);
  36. bundle.putParcelable(AccountManager.KEY_INTENT, intent);
  37. return bundle;
  38. }
  39.
  40. @Override
  41. public Bundle getAuthToken(AccountAuthenticatorResponse response, Account account, String authTokenType, Bundle options)
  42. throws NetworkErrorException {
  43. // Authentication sample code
  44. String authToken = accountManager.peekAuthToken(account, getString(R.string.account_token_type));
  45. //if not , might be expired, register again
  46. if (TextUtils.isEmpty(authToken)) {
  47. final String password = accountManager.getPassword(account);
  48. if ( password != null ) {
  49. //get new token
  50. authToken = account.name + password ;
  51. }
  52. }
  53. //without password , need to sign again
  54. final Bundle bundle = new Bundle();
  55. if (!TextUtils.isEmpty(authToken)) {
  56. bundle.putString(AccountManager.KEY_ACCOUNT_NAME, account. name );
  57. bundle.putString(AccountManager.KEY_ACCOUNT_TYPE, account.type);
  58. bundle.putString(AccountManager.KEY_AUTHTOKEN, authToken);
  59. return bundle;
  60. }
  61.
  62. // no account data at   all , need to do a sign
  63. final Intent intent = new Intent(context, AuthActivity.class);
  64. intent.putExtra(AccountManager.KEY_ACCOUNT_AUTHENTICATOR_RESPONSE, response);
  65. intent.putExtra(AuthActivity.ARG_ACCOUNT_NAME, account. name );
  66. bundle.putParcelable(AccountManager.KEY_INTENT, intent);
  67. return bundle;
  68. }
  69.
  70. @Override
  71. public String getAuthTokenLabel(String authTokenType) {
  72. // throw new UnsupportedOperationException();
  73. return   null ;
  74. }
  75.
  76. @Override
  77. public Bundle editProperties(AccountAuthenticatorResponse response, String accountType) {
  78. return   null ;
  79. }
  80.
  81. @Override
  82. public Bundle confirmCredentials(AccountAuthenticatorResponse response, Account account, Bundle options)
  83. throws NetworkErrorException {
  84. return   null ;
  85. }
  86.
  87. @Override
  88. public Bundle updateCredentials(AccountAuthenticatorResponse response, Account account, String authTokenType, Bundle options)
  89. throws NetworkErrorException {
  90. return   null ;
  91. }
  92.
  93. @Override
  94. public Bundle hasFeatures(AccountAuthenticatorResponse response, Account account, String[] features)
  95. throws NetworkErrorException {
  96. return   null ;
  97. }
  98. }
  99. }

  • Declare Account Service
  1. <service
  2. android: name = "**.XXAuthService"
  3. android:exported= "true"
  4. android:process= ":core" >
  5. <intent-filter>
  6. < action
  7. android: name = "android.accounts.AccountAuthenticator" />
  8. </intent-filter>
  9. <meta-data
  10. android: name = "android.accounts.AccountAuthenticator"
  11. android:resource= "@xml/authenticator" />
  12. </service>

The authenticator is:

  1. <?xml version= "1.0" encoding= "utf-8" ?>
  2. <account-authenticator xmlns:android= "http://schemas.android.com/apk/res/android"
  3. android:accountType= "@string/account_auth_type"
  4. android:icon= "@drawable/icon"
  5. android:smallIcon= "@drawable/icon"
  6. android:label= "@string/app_name"
  7. />

  • Using Account Services

Same as SyncAdapter, used through AccountManager

Token application is mainly through AccountManager.getAuthToken) series of methods

. Adding an account is done through AccountManager.addAccount)

. Check if the account exists through AccountManager.getAccountsByType)

Refs

  • WeChat Android client background keep alive experience sharing
  • Android Low Memory Killer Principle
  • The dual service method introduced on stackOverflow
  • Write your own Android Sync Adapter
  • Write your own Android Authenticator
  • Android developer
    • android.accounts
    • AccountManager
    • AbstractAccountAuthenticator
    • AccountAuthenticatorActivity
    • Creating a Sync Adapter
  • Android article: Implementing from the bottom layer to prevent the process from being killed (failed Closed)
  • Use of NotificationListenerService in Android 4.3+
  • Going multiprocess on Android
